Basic Functions
|
Range
|
Accuracy
|
Technical parameters
|
| Insulation Resistance Test |
class I PASS Value 1MΩ |
±0.1MΩ |
Output Voltage 500V |
| class II PASS Value 2MΩ |
Output Current (R=500KΩ): >1mA |
| cord PASS Value 2MΩ |
Short-circuit current<3mA |
| Ground Resistance |
class I PASS Value 0.2Ω |
±0.03Ω |
Measuring current >200mA ( R<2Ω ) |
| cord PASS Value 0.2Ω |
Measuring voltage 5v DC |
| Crod test |
Correct wiring |
√Cord Fault(DL-8101 Prompt √Lead Fault) |
Open circuit, short circuit,
reverse polarity |
×Cord Fault(DL-8101 Prompt ×Lead Fault) |
| Out with testing |
Normal |
Bitmap
|
|
| Off ground |
Prompt“LN√，LE×，NE×” |
| Out zero line |
Prompt“LN×，LE √，NE× |
| Special Functions |
|
|
|
| Sleep mode |
√ |
|
|
| Low Battery Display |
√ |
|
|
