Pin Static Brinell Hardness Tester

       Description: Pin Static Brinell hardness tester is manufactured according to the Brinell hardness test method. The test force is controlled by a shear pin.  After reading  the diameter of the indentation with the reading microscope, the Brinell hardness value can be obtained from the Indentation Brinell Hardness Table.

        Suitable for testing: the hardness of forgings, castings, steels, nonferrous metal and its alloy products, and to test the hardness of annealed,  normalizing and tempered mechanical parts.

Specification:

Test Force:1,580 kgf

Indenter: 7.26mm Steel ball indenter,

                  test range 100~350HBW

                  4mm Carbide ball Indenter,

                  test range 350~650HBW

Indicator Error: ≤2~3% Comply with ISO, ASTM

Repeatability Error:≤2~3% Comply with ISO,  ASTM

Test Range: 100~650HBW

Opening dimension: 150mm(Height) x100mm       (Throat Depth)

Net Weight : 4.2 kg

Application: Castings, Forgings, Steel Products,   Heat Treatment

Packing List:

  -C frame  1

  -7.26mm carbide ball indenter 1

  -Shear pin housing  1

  -Handle   1

  -Brinell hardness Block  1

  -Shear Pin (250 pieces/box) 1

  -Pin clearner  1

  -20* Reading Microscope  1

  -Carrying Case  1
