Features:
-Two types of measuring methods.
-Probe can be changeable
-With temperature compensation
-With rotatable display, Display can be set.
-Display: 2.4 TFT ture color display,320*240
-The speed of measurement can be set. Single or continuous
-Three types of calibration, and modify the error from probe. zero, 2 points and system.
-10000 measuring data storage,
-With deleting function, deleting all or single data.
-Tolerance: can be set and automatically alarm the data out of tolerance.
-Two lanugage: English and Chinese
-Metric and Inch can be convertible.
-Wireless transmit: bluetooth 2.0. connecting to PC or printer.
-Low power Indicator
-Manual or auto power off
-V groove for tube measurement
-Large probe
Specification:
-6 different type of probe: F0.5, F1.2, F3, F5, F9, N1.2
-Measuring method of probe:
Magnetic induction(F0.5,F1.2,F3,F5,F9)
Electric eddy-current(N1.2)
-Measuring range of probe:
F0.5 (0-0.5mm)
F1.2 (0-1.25mm)
F3 (0-3mm)
F5 (0-5mm)
F9 (0-9mm)
N1.2 (0-1.25mm)
-Detecting resolution of probes:
F1.2, F3 ( 0.1um)
F5, F9 (10um)
N1.2 (0.1um)
-Deviation of probe: ±(1-3%)H±1or±2um H is the real thickness of coating
-Accuracy of probe: 0-100um: 0.1um 100-999um: 1um 1-9mm:0.01mm
|
|
F0.5
|
F1.2
|
F3
|
F5
|
F9
|
N1.2
|
|
Min plane diameter for matrix
|
6mm
|
9mm
|
12mm
|
20mm
|
20mm
|
9mm
|
|
Min radius of matrix(concave)
|
5mm
|
6mm
|
7.5mm
|
10mm
|
10mm
|
6mm
|
|
Min radius of matrix(convex)
|
1.5mm
|
1.5mm
|
2mm
|
5mm
|
5mm
|
1.5mm
|
