Features:
- Double measurement: Support ultrasonic probe and Leeb impact device. Wider application
- The tester is made by metal shell, shield electronmagnetic interference
- Large color display.
- ax, Min , Ave value
- Bluetooth transferring
- Saving 1000 groups data
- Save 20 groups calibration data withouth doing calibration for the same material.
specifications:
| Product name |
Dynasonic Hardness Tester; |
| Model |
ULHT-3004 |
| Ultrasonic Probe |
Standard delivery:2Kgf(optional Manual 1Kgf、5Kgf、10Kgf，motorized 0.3Kg and 1Kgf) |
| Impact Devices |
Standard delivery:D(optional DC,DL,D+15,C, G) |
| Hardness Scale |
HL, HV,HB,HRC,HRB,HRA,HS, etc. |
| Measuring Range |
HV:50～1599; HRC:20～68; HB:76～650;
HRB:41～105; HLD:170～960 |
| Measuring Accuracy |
HV:±3%HV; HRC:±1.5HRC; HB:±3%HB;HL: ±8HL |
| Resolution |
0.1HR, 1HV, 1HB, 1HLD,0.1HS |
| Result Display |
Measurement value, Max, Min, Ave, single mode, batch mode, etc. |
| Data Storage |
1000 group test results and 20 group calibration data |
| Data Transfer |
Bluetooth |
| Continuous Working Period |
10h (turn off the back light) |
| Operating Environment |
Temperature: -10℃~50℃; Humidity: 30%~80% |
| Operating Voltage |
4.2V |
| Charge Mode |
USB |
| Dimension |
160x80x31mm |
| Weight |
≤500g(probe not included) |
Packing list:
- The tester
- 2KG manual probe
- Impact devices type D
- Rockwell hardness Block
- Leeb hardness block
- Probe Cable
- USB Cable
- Manual
