Portable Colorimeter Color Difference Meter 8mm
Zoom Browse
Product Name: Portable Colorimeter Color Difference Meter 8mm
Product Numbers: CDME-1028
Product Specifications: Measurement Caliber 8mm
Product Unit: Display Mode CIELAB、CIELCH
Product Remark: Light Source LED blue excitation
Product Class:Measuring and Testing Instruments > Optical Instruments > Portable Color difference Meters
Product Details
【DateTime:2014-07-25 Browse:】【Font: Big Mid Small】【Print】【Close
Portable Colorimeter Color Difference Meter 8mm
CDME-1028
Desicriptions:
     With competitive price, has these advantages of being easy to operate, easy to understand, affordable and so on. CDME-1028 only have one measuring light source (D65); two kinds of color modes (CIE1976LAB, CIELCH); one color difference formula (△ E * ab); two language pattern (Simplified Chinese and English), and a universal measuring caliber (8MM) . CDME-1028 colorimeter can store 100 standard data and 20000 sample data, you can also add mini-printers to do real-time printing measurement data. It can’t operate with "color analysis system" software functions.

Specifications:
Display Mode   CIELAB, CIELCH
Color Difference Formula   E*ab
Illumination Condition   CIE Recommendation: 8/d
Light Source   LED blue excitation
Sensor   Photodiode array
Measurement Caliber   φ8mm
Measurement Condition   Observer: CIE 10° Standard observer
  Light source: D65
  Contain light way
: SCI SCE
Measurement Range   L: 0 to 100
Repeated Accuracy   E<0.07(take the deviation average after 30 times measuring the whiteboard)
Table Difference   E<0.2
Measurement Interval   0.5 Sec.
Storage Capacity   Type sample data : 100 with testing sample data: 200

Language Patterns   Simplified Chinese/English
Battery Charging Time   8 hrs
Battery   Li-ion battery, 5000 times Measurement
Lifetime of Bulb   5 years more than 1.6 million measurements
Display Screen   TFT true color 2.8inch@(16:9)  Resolution ratio:400x240
Interface of External   RS-232 (115200bps)- connected with micro printer
Working Temperature Range   0-40 degree(32-104℉)
Storage Temperature Range   -20-50 degree(-4-122℉)
Humidity Range   Relative humidity less than 85%,without condensation
Weight   700g
Size   199*68*90mm
Size of Exterior Package   400*240*340mm
Standard Accessories   3000mAH Li-ion battery/AC adapter/User manual/Warranty card
Optional Accessories   Flour measuring device/Liquid measuring device/Micro printer
