Seidentopf Binocular Head Biological Microscope
Zoom Browse
Product Name: Seidentopf Binocular Head Biological Microscope
Product Numbers: BIMI-21501
Product Specifications: Eyepiece WF10×/20mm (23.2mm)
Product Unit: Nosepiece Quintuple
Product Remark: 3W-LED Illumination
Product Class:Measuring and Testing Instruments > Optical Instruments > Microscope
Product Details
【DateTime:2020-01-03 Browse:】【Font: Big Mid Small】【Print】【Close

Independent Phase Contrast Unit Biological Microscope

Features:

- Quintuple turret phase contrast unit with 10X/20X/40X/100X infinity plan phase contrast objective for phase contrast and  bright field observation

- Dark field condenser(dry)available to 4X-40X Objective.

- Dark field condenser (wet) available to 100X Objective.

- 0X/20X/40X/100X Independent Phase Contrast Unit.

- Six-holes disk fluorescence unit, More fluorescence filters can be supplied

Specification:

Items

Specification

Outfits

Eyepiece

WF10×/20mm (23.2mm)

●●

Infinity Plan Objectives

PLAN 4×/0.10

W.D.=12.10mm

PLAN 10×/0.25

W.D.=4.64mm

PLAN 20×/0.40(S)

W.D.=2.41mm

PLAN 40×/0.66(S)

W.D.=0.65mm

PLAN 100×/1.25(S, Oil)

W.D.=0.12mm

PLAN 2.5×/0.07

W.D.=8.47mm

PLAN 60×/0.80(S)

W.D.=0.33mm

PLAN 100×/1.15(S, W)

W.D.=0.19mm

Seidentopf Binocular Head

Inclined 30°,Rotatable 360°, Interpupilary Distance:48mm-75mm

Seidentopf Trinocular Head

Inclined 30°,Rotatable 360°, Interpupilary Distance:48mm-75mm,

Light Distribution: 100: 0 / 80:20

Nosepiece

Quintuple

Mechanical Stage

Stage Size: 175mm×145mm,Travel: 78mm×55mm
Coaxial Coarse and Fine Focusing Knobs
Two Slide Holder

Integrated stage

Stage size: 182 mm×140mm,Travel range: 77mm×52mm
Two-slide holder

Condenser

Abbe N.A. 1.25 with iris diaphragm.

Swing Out Condenser, N.A. 0.9/0.13, with iris diaphragm.

Koehler Illumination

Wide voltage input: 100V~240V

Field diaphragm , center adjustable

12V/20W Halogen Lamp

6V/30W Halogen Lamp

3W-LED Illumination

Filter

Blue

Green /Amber /Grey

C-mount

1×/0.5×/0.75×C-mount (focus adjustable

Fluorescence Attachment

Epi fluorescence unit ( six-hole disc media which can be fixed with Uv /V/B/G and another filters) ,100W mercury lamp.

Epi fluorescence unit ( six-hole disc media which can be fixed Uv /V/B/G), 5W-LED fluorescence lamp.

Phase Contrast Unit

Quintuple hole turret

10× /20× /40× /100× phase contrast objective

Independent slot

10× /20× /40× /100× phase contrast objective

Dark Field Unit

Dark field condenser (dry),apply to 4×- 40× objective

Dark field condenser (wet),apply to 100× objective

Polarizing Attachment

Analyzer / Polarizer

Note: "●"In Table Is Standard outfits, "○" Is Optional Accessories.

Packing Size: 542mm×265mm×355mm     Gross Weight: 12 kgs     Net Weight: 10kgs
