20 60 85 Degree Gloss Meter with High Accuracy
Gloss meter GLME-5268 functional description
(1) One button to complete triangle measurement: one operation can complete three angle measurement; Measuring light incident angle meet ISO 2813 three measuring light incident angle. Three incidenct angle of mirror gloss meter is 20 °, 60 °, 85 ° respectively;
(2) Optional angle mode: choose measuring angle or angle combination according to user needs.
(3) Manually entering standard samples gloss data;
(4) Humanized design, good man-machine communication interface;
GLME-5268 specification：
|
Specification
|
Unit
|
Triangle Gloss Meter
|
|
Measuring Angle
|
degree
|
20° 60° 85°
|
|
Measuring Range
|
GU
|
20°:0-2000
60°:0-1000
85°:0-160
|
|
Measuring Spot
|
mm
|
20°: 10x10
60°:9x15
85°:5x38
|
|
Measuring Spot
|
GU
|
0-1000:0.1 1000-2000:1
|
|
Repeatability
|
GU
|
0-100:0.2 >100:0.2%
|
|
Indication Error
|
GU
|
±1.5
|
|
Zero Error
|
GU
|
0.2
|
|
Working Temperature Range
|
℃
|
10℃ - 40℃
|
|
Storage Temperature Range
|
℃
|
-10℃ - 70℃
|
|
Humidity Range
|
|
Relative humidity less than 85%,without condensation
|
|
Power Adapter
|
|
Section 2 5 alkaline batteries/power adapter
|
|
Volume
|
mm
|
159x49x72
|
|
Weight
|
g
|
500
|
