Digital Bevel Box with Bubble (Plastic Frame)
Zoom Browse
Product Name: Digital Bevel Box with Bubble (Plastic Frame)
Product Numbers: BB-03
Product Specifications: readings between ±180°
Product Remark: Digital Bevel Box
Product Class:Measuring Tools > Angle and Square > Bevel Box
Product Details
【DateTime:2010-07-30 Browse:】【Font: Big Mid Small】【Print】【Close
Features:
 Mini digital protractor that provides digital readings between ±180°
• Integral magnets in the base for accuracy
• Ideal for measuring mitre and bevel angles on saw benches etc.
• Auto shut off after 5 minutes
• Comes complete with soft case and battery
Bevel Box Description:
1.whole metal shell or plasctic panel
2.with 3 button: ZERO,ON/OFF,ABS/ZERO
3.automatic shut off after 5 minutes
4.in horizontal measuring ,the accuracy is more higer with the highly accurate bubble.
5.with 3 disk magnet on the bottom,easy to attach to other tools.
6.resolution:0.1 degree
  repeatability:0.1 degree
  accuracy of level bubble:2/6
  range:degree
Order No
Range
Resolution
Accuracy
 Remarks
BB-03
±180.00°
0.1°
±0.1°
 plastic panel and back with bubble
