--Robust against dust, particles, oil, grease, humidity, liquids.

   --Optional with cable, connector and encoder-holder.

   --The infrared wave length:880nm

  --Reading head sliding system:vertical or 45°five precision bearing system

  --Grating system:The tansmissive and infared optical measuring system

   --Sectional Dimensions(mm)   27x44
   --Accuracy   ±3/±5/±10um(20°C/68°F)
   --Biggest Working Speed:  60m/min
   --Zero Reference Point: 1 per 100mm
   --Sealing Protection:  IP55
   --Resolution(um):  0.5/1/5
   --Output signal:  TTL/EIA-422-A/1Vpp
   --Voltage:  5V/12V/24V/36V

  --Cable: 5m

Order No	Range	Resolution
LISC-10201	1100mm	0.005mm
LISC-10202	1200mm	0.005mm
LISC-10203	1300mm	0.005mm
LISC-10204	1400mm	0.005mm
LISC-10205	1500mm	0.005mm
LISC-10206	1600mm	0.005mm
LISC-10207	1700mm	0.005mm
LISC-10208	1800mm	0.005mm
LISC-10209	1900mm	0.005mm
LISC-10210	2000mm	0.005mm
LISC-10211	2100mm	0.005mm
LISC-10212	2200mm	0.005mm
LISC-10213	2300mm	0.005mm
LISC-10214	2400mm	0.005mm
LISC-10215	2500mm	0.005mm
LISC-10216	2600mm	0.005mm
LISC-10217	2700mm	0.005mm
LISC-10218	2800mm	0.005mm
LISC-10219	2900mm	0.005mm
LISC-10220	3000mm	0.005mm
