0-25mm has a smaller diameter on the spindle and anvil for measuring splined shafts, slots, and keyways, for measuring of slots and keyways
Features:
Micro-lapped carbide tipped measuring face gives mirror finish on the measuring faces to make more accurate reading
Microfine graduation on satin chrome finish on spindle sleeve to increase readability
Advanced spindle design in hardened and precision ground lead screw threads give reliable and accurate reading
Ratchet stop allows uniform pressure of spindle to the contact and enhance measurement repeatability
Lock nut and ratchet stop standard
Measuring range: 0-25mm or 1
Anvil diameter: 2mm
Resolution:0.01mm
Accuracy:0.004mm(4μ)
Packed in wooden box or plastic box.
